2023-12 add fluorescence monitor plot to end of page
2023-10-20 update plots based on duration: 1h plot every minute, 2h plot every 2nd minute, 4h plot every 4th minute, 8h plot 8th minute, longer every 16th minute
2023-10-xx improved zeeman peak servo plot
2023-10-15 ADEV(B1,B2,B4) plot, remove y18 plot, update AHM3 model from AB2023-10
2023-10-08 log-spaced tau-points in self-comp. plot (g-ratio - 1.668).
2023-05-05 text-files with B-field per servo-cycle
2023-05-04 self-comparison ADEV: change from mean(ADEV) to mean(AVAR)
2023-05-03 QPN-line: change FWHM/2 (Lorentzian line) to FWHM/3 (Rabi lineshape), lowers QPN estimate by 1/1.5
2023-05 move interleave clockrun figure to lowest row
2023-04-21 Migrated plotting to new computer.
2023-02-13 Interleaved clockrun result plot: ExtraOrdinary - Ordinary servo line-center difference
2022-06-29 EQS-free self comparison: ADEV( 3*(C2-Cmean)-2*(C1-Cmean)-(C4-Cmean) ) / (sqrt(3)*sqrt(14) )
2022-03-22 photon count distribution over n_shots, image
2022-03-15 add plot of individual Zeeman component servos, with offsets to bring all values close together
comparison against AHM2 (and AHM1?) model, via maser-phasemeter data?
2022-03-08 Quantum jumps in 2nd detection window. binomial distribution for 1st window jumps
2022-01-18 better servo cycle duration plot, with dead-time. S-balance based on previous 10 servo-cycles
2022-01-16 average quantum jumps during past 10 servo cycles, adev of g-ratio
2022-01-06 'S-balance' plot to compare C+ and C- peak heights?
2022-01-05 optical frequencies in real time. both Hz and 1e-18 units?
2022-01: errorbars for self-comparison ADEV, g-ratio
2021-12: Dsum plot, B1/B2/B4 histograms
2021-02-04 Add QPN-limit to ADEV plot. Add servo-cycle duration plot. Add EQS-slope plot. 2nd-order servo I-term
2021-02-02 clock-run with 60ms probe (new mu-shields)
2020-11-18 page created. PMT count plot is new.

Data archive: https://monitor.mikes.fi/ftp/IonClock/comb_ftp/
Plots update every 10 minutes (plot_ion.py on ionclock-machine)

data	32 h	16 h	8 h	4 h	2 h	60 min
Line-center vs. maser, Hz 1 point/servo-cycle
Line-centers, AOM Center_C1_1920.txt Center_C2_1920.txt Center_C4_1920.txt Center_C124_1920.txt mean(C1,C2,C4)
Zeeman components
2nd-order servo I-term (should converge to un-compensated drift value)
Line-centers, differences
Self-comparison stability
PMT counts
Magnetic field Bfield_C1_1920.txt Bfield_C2_1920.txt Bfield_C4_1920.txt
EQS slope (prefactor of mjprime-squared expression)
Servo-cycle length
g-ratio
g-ratio ADEV
S-balance
Quantum jumps during past 10 servo cycles
Quantum jumps, 1st detection Window
Quantum jumps, 2nd detection Window
+C1 quantum jumps
-C1 quantum jumps
+C2 quantum jumps
-C2 quantum jumps
+C4 quantum jumps
-C4 quantum jumps
Interleaved clockrun difference
Fluorescence monitoring DIO counts
